Giới thiệu Bộ lưu điện online 1kva; ups online 1kva; máy tích điện 1000va; ups 100va; lưu điện 1000va
CHI TIẾT SẢN PHẨMUPS MODELHL-1K
PHASESingle phase with ground
Capacity (VA/Watts)1000VA/900W
In put
Normal Voltage100VAC - 300VAC
Frequency Range40HZ - 70HZ
Power factor>= 0.99%load (Nominal Input Voltage)
Bypass voltage rangeBypass high voltage point
For 200/208/220/230/240 VAC models:
230-264: setting the high voltage point in LCD from 230Vac to 264Vac (Default:264Vac)
For 100/110/115/120/127 VAC models:
115-132: setting the high voltage point in parameter 3 from 115Vac to 132Vac (Default:132Vac)
Bypass low voltage point
For 200/208/220/230/240 VAC models:
170-220: setting the low voltage point in LCD from 170Vac to 220Vac (Default: 170Vac)
For 100/110/115/120/127 VAC models:
95-110: setting the low voltage point in parameter 3from 95Vac to 110Vac (Default:95Vac)
ECO rangeSame as bypass
Generator inputSupport
Out Put
Voltage200/208/220/230/240VAC (Output can be adjustable)
Frequency AC mode in sync with AC(45-55)HZ battery mode(50/60HZ)
Power factor0.9
Voltage regulation±2%(Batt. Mode)
OutPut waveformPure sine wave
Crest factor3ꓽ1
Harmonic distortionlinear load<= 3% non-linear<= 6%
Transfer timeZero second transfer
Overload capacity105%-110%:battery mode 10mins shutdown, AC mode 10mins transfer to bypass mode
110%-130%:battery mode 1mins shutdown, AC mode 1mins transfer to bypass mode
>130%:battery mode 3seconds shutdown, AC mode 1second transfer to bypass mode
Efficiency
AC mode>88%
Battery mode>83%
Battery
Battery Type12V9AH
Numbers2
Backup timeLong run unit depends on the capacity of external batteries
Typical recharge time4 hours recover to 90% capacity (Typical)
Rated voltage24VDC
Charging voltage27.4VDC
Charging Current1A
Temperature0 ᵒC- 40ᵒC
Humidity0 - 90%(Non-condensate)
Noise<50db
Altitude<1500m
PHYSICAL
DimensionsW144*H224*D285mm
Net weight(Kg)8.5
Safety standardIEC/EN62040-1, IEC/EN60950-1
EMCIEC/EN62040-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-8
Chi Tiết Sản Phẩm
| Bảo Hành | 36 tháng |
|---|
