Giới thiệu Mainboard Asrock AB350M Pro4 hàng cũ

Mainboard Asrock AB350M Pro4 hàng cũ.
Hàng bán ra là hàng cũ nên chỉ có main+ chặn FE, không có các thứ chip, ram quạt,...
Chipset: AMD B350.
Socket: AM4.
Hỗ trợ CPU: Supports AMD Socket AM4 A-Series APUs (Bristol Ridge) and Ryzen Series CPUs (Summit Ridge).
Cạc đồ họa: VGA onboard.
Kích thước: mATX.

Mainboard Asrock AB350M Pro4 hàng bóc máy, nguyên bản
Chi tiết về sản phẩm : Mainboard Asrock AB350M Pro4
CPU: – Supports AMD Socket AM4 A-Series APUs (Bristol Ridge) and Ryzen Series CPUs
(Summit Ridge)
– Digi Power design
– 9 Power Phase design
– Supports 95W Air Cooling
Chipset
: – AMD Promontory B350

Memory
: – Dual Channel DDR4 Memory Technology
– 4 x DDR4 DIMM Slots
– AMD Ryzen series CPUs support DDR4 3200+(OC)/2933(OC)/2667/2400/2133 ECC &
non-ECC, un-buffered memory*

Graphics

: – Integrated AMD Radeon™ R-Series Graphics in A-series APU*
– DirectX 12, Pixel Shader 5.0
– Max. shared memory 2GB
– Three graphics output options: D-Sub, DVI-D and HDMI

Audio

: – 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)*
– Premium Blu-ray Audio support

Lan

: – PCIE x1 Gigabit LAN 10/100/1000 Mb/s
– Realtek RTL8111GR
– Supports Wake-On-LAN
– Supports Lightning/ESD Protection

Optical
: Yes
LAN
: Gigabit Ethernet, 10/100/1000
Slots
: AMD Ryzen series CPUs
– 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*
– 1 x PCI Express 2.0 x16 Slot (PCIE3: x4 mode)
AMD 7th A-Series APUs
– 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode)*
– 1 x PCI Express 2.0 x16 Slot (PCIE3: x4 mode)
– 1 x PCI Express 2.0 x1 Slot
Storage
: – 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and
Hot Plug*
– 1 x Ultra M.2 Socket (M2_1), supports M Key type 2242/2260/2280 M.2 PCI Express module up
to Gen3 x4 (32 Gb/s) (with Ryzen Series CPU) or Gen3 x2 (16 Gb/s) (with A-Series APU)**
– 1 x M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s
module**
