Dây Cáp Cảm Biến Nhiệt Độ Ds18B20 1 2 3 Mét Màu Đen Bằng Thép Không Gỉ Chống Nước Cho Arduino
Mô tả ngắn
Mua Dây Cáp Cảm Biến Nhiệt Độ Ds18B20 1 2 3 Mét Màu Đen Bằng Thép Không Gỉ Chống Nước Cho Arduino giá rẻ nhất ở đâu?Sản phẩm cùng danh mục
Gợi ý từ dữ liệu sản phẩm đã index trên TecKi.
Sản phẩm cùng tầm giá
Các lựa chọn gần mức giá hiện tại để người dùng so sánh nhanh.
Giới thiệu Dây Cáp Cảm Biến Nhiệt Độ Ds18B20 1 2 3 Mét Màu Đen Bằng Thép Không Gỉ Chống Nước Cho Arduino
Operating temperature range:-55°C to +125°C (-67°F to +257°F)
Size of Stainless steel sheath:6*50mm
Length of Cable : 100CM , 200CM , 300CM
Power supply range: 3.0V to 5.5V
Accuracy over the range of -10°C to +85°C: ±0.5°C.
Storage temperature range:-55°C to +125°C (-67°F to +257°F)
Output leads: Yellow (VCC), Red (DATA), Black (GND)
Package include:1*DS18B20 sensor
Using the original DS18B20 temperature sensor probe
High quality stainless steel tube waterproof moisture-proof rust
Stainless steel shell (6*50mm), lead length 100cm
Each probe after strict test independent packaging
3.0V ~ 5.5V power supply
9 ~ 12 adjustable resolution
The temperature range of -55 ~ +125
No external components, the single bus interface unique
The output leads: red (VCC), yellow (DATA), black (GND)
Note: RED - VCC, GREEN - DATA, YELLOW - GND
Shipping list:
1M: 1 meter length DS18B20 sensor *1
2M: 2 meter length DS18B20 sensor *1
3M: 3 meter length DS18B20 sensor *1
