Giới thiệu Bảng mạch khuếch đại âm thanh kỹ thuật số TPA3110 2X15W kết nối Bluetooth chuyên dùng
#TPA3110 #2X15W #Digital #Stereo #Bluetooth-compatible #Audio #Power #Amplifier #BoardTPA3110 2X15W Digital Stereo Bluetooth-compatible Audio Power Amplifier Board
Description:
This is an audio power amplifier board that strengthens low-power, inaudible electronic audio signals such as the signal from radio receiver or electric guitar pickup to a level that is strong enough for driving loudspeakers or headphones. Power amplifiers make the signal audible to listeners. It is the final electronic stage in a typical audio playback chain before the signal is sent to the loudspeakers and speaker enclosures.
Features:
Digital amplifier has a higher overload capacity than analog amplifier, and it won't cause crossover distortion, transient inter modulation distortion and you don't have to worry about the loudspeaker internal resistance.
It supports Bluetooth-compatible audio input and the maximum receiving distance is 10 meters.
Dual channel of 15W+15W power output and a wide input voltage range from 10V to 25V DC.
Sound quality is very good by using this audio power amplifier module.
Applicable speaker impedance are 4/6/8/10 ohm, great for turning normal speaker into Bluetooth-compatible speaker.
Specifications:
Audio Input: Bluetooth
Bluetooth-compatible Max. Distance: 10 meters
Output Power: Dual channel (15W+15W)
Suitable Impedance: 4, 6, 8, 10 ohm speaker
Input Voltage: 10~25V DC (suggest 12V DC, 2A above; speaker power is less than 12V DC, 1A)
Power Supply Connector: 2.54mm, 3PIN
Speaker Connector: 2.54mm, 2PIN
Size: 58x38mm/2.28x1.5"
Quantity: 1 Pc
Note:
Please allow 0-1mm error due to manual measurement. pls make sure you do not mind before you bid
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
No Retail Package
Package Contents:
1 x Amplifier Board
